SV40 promoter

Simian virus 40 (SV40) enhancer and early promoter, with the SV40 origin of replication.
Try SnapGene for Free
|Download SnapGene Viewer
Explore Over 2.7k Plasmids: Basic Cloning Vectors | More Plasmid Sets
No matches
HomePlasmidsBasic Cloning VectorsSV40 promoter
300 200 100 End (317) AvrII (302) StuI (301) BseRI (298) SfiI - BglI (255) BtgI - NcoI (209) BmrI (181) CsiI SexAI * (69) Start (0) SV40 promoter SV40 ori SV40 promoter 317 bp
End  (317)
0 sites
AvrII  (302)
1 site		 C C T A G G G G A T C C
StuI  (301)
1 site		 A G G C C T T C C G G A
BseRI  (298)
1 site		 G A G G A G ( N ) 8 N N C T C C T C ( N ) 8
Sticky ends from different BseRI sites may not be compatible.
BseRI quickly loses activity at 37°C.
Prolonged incubation with BseRI may lead to degradation of the DNA.
SfiI  (255)
1 site		 G G C C N N N N N G G C C C C G G N N N N N C C G G
Efficient cleavage requires at least two copies of the SfiI recognition sequence.
Sticky ends from different SfiI sites may not be compatible.
BglI  (255)
1 site		 G C C N N N N N G G C C G G N N N N N C C G
Sticky ends from different BglI sites may not be compatible.
BtgI  (209)
1 site		 C C R Y G G G G Y R C C
Sticky ends from different BtgI sites may not be compatible.
NcoI  (209)
1 site		 C C A T G G G G T A C C
BmrI  (181)
1 site		 A C T G G G ( N ) 4 N T G A C C C ( N ) 4
The 1-base overhangs produced by BmrI may be hard to ligate.
Sticky ends from different BmrI sites may not be compatible.
Unlike most restriction enzymes, BmrI can cleave DNA in the absence of magnesium.
CsiI  (69)
1 site		 A C C W G G T T G G W C C A
Sticky ends from different CsiI sites may not be compatible.
SexAI  (69)
1 site		 A C C W G G T T G G W C C A
* Blocked by Dcm methylation.
Sticky ends from different SexAI sites may not be compatible.
Start  (0)
0 sites
SV40 promoter
1 .. 317  =  317 bp
SV40 enhancer and early promoter
SV40 promoter
1 .. 317  =  317 bp
SV40 enhancer and early promoter
SV40 ori
168 .. 303  =  136 bp
SV40 origin of replication
SV40 ori
168 .. 303  =  136 bp
SV40 origin of replication
ORF:  2 .. 265  =  264 bp
ORF:  87 amino acids  =  9.9 kDa  (no start codon)
