lambda

Complete annotated DNA sequence of bacteriophage lambda, including the cohesive ends.
Try SnapGene for Free
|Download SnapGene Viewer
Explore Over 2.7k Plasmids: Basic Cloning Vectors | More Plasmid Sets
No matches
HomePlasmidsBasic Cloning Vectorslambda
40,000 30,000 20,000 10,000 End (48,502) PluTI (45,683) SfoI (45,681) NarI (45,680) KasI (45,679) orf-64 Nin 221 Nin 204 Nin 60 cII cII cII rho utilization site B rho utilization site A cro operator-r1 operator-r2 operator-r3 rexb rexb rexb operator-l3 operator-l2 operator-l1 Nutl binding site BmtI (34,683) NheI (34,679) ral ea10 XhoI - PspXI - PaeR7I (33,498) kil SgrDI (33,244) gam recombination site xis xis xis KflI (28,798) int 3 binding site int 2 binding site int 1 binding site XbaI * (24,508) recombination site orf-314 NaeI (20,042) NgoMIV (20,040) BsiWI (19,323) lom SnaBI (12,190) ApaI (10,090) PspOMI (10,086) G Fii D Start (0) A B nu3 E Fi Z V H L I J orf-401 orf206b orf206b int bet N Nin 290 R nu1 W mature peptide U T M K orf206b orf-194 orf206b xis xis exo ral ice cII Nin 68 Q S Rz leader peptide C xis lambda 48,502 bp
End  (48,502)
0 sites
PluTI  (45,683)
1 site		 G G C G C C C C G C G G
Efficient cleavage requires at least two copies of the PluTI recognition sequence.
SfoI  (45,681)
1 site		 G G C G C C C C G C G G
NarI  (45,680)
1 site		 G G C G C C C C G C G G
Efficient cleavage requires at least two copies of the NarI recognition sequence.
KasI  (45,679)
1 site		 G G C G C C C C G C G G
BmtI  (34,683)
1 site		 G C T A G C C G A T C G
NheI  (34,679)
1 site		 G C T A G C C G A T C G
XhoI  (33,498)
1 site		 C T C G A G G A G C T C
PspXI  (33,498)
1 site		 V C T C G A G B B G A G C T C V
PaeR7I  (33,498)
1 site		 C T C G A G G A G C T C
PaeR7I does not recognize the sequence CTCTCGAG.
SgrDI  (33,244)
1 site		 C G T C G A C G G C A G C T G C
KflI  (28,798)
1 site		 G G G W C C C C C C W G G G
Sticky ends from different KflI sites may not be compatible.
XbaI  (24,508)
1 site		 T C T A G A A G A T C T
* Blocked by Dam methylation.
NaeI  (20,042)
1 site		 G C C G G C C G G C C G
Efficient cleavage requires at least two copies of the NaeI recognition sequence.
NgoMIV  (20,040)
1 site		 G C C G G C C G G C C G
Efficient cleavage requires at least two copies of the NgoMIV recognition sequence.
BsiWI  (19,323)
1 site		 C G T A C G G C A T G C
BsiWI is typically used at 55°C, but is 50% active at 37°C.
SnaBI  (12,190)
1 site		 T A C G T A A T G C A T
ApaI  (10,090)
1 site		 G G G C C C C C C G G G
ApaI can be used between 25°C and 37°C.
PspOMI  (10,086)
1 site		 G G G C C C C C C G G G
Start  (0)
0 sites
A
711 .. 2636  =  1926 bp
641 amino acids  =  73.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: A; DNA packaging;641
A
711 .. 2636  =  1926 bp
641 amino acids  =  73.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: A; DNA packaging;641
B
2836 .. 4437  =  1602 bp
533 amino acids  =  59.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: B (capsid component;533)
B
2836 .. 4437  =  1602 bp
533 amino acids  =  59.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: B (capsid component;533)
nu3
5132 .. 5737  =  606 bp
201 amino acids  =  20.8 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: nu3 (capsid assembly;201)
nu3
5132 .. 5737  =  606 bp
201 amino acids  =  20.8 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: nu3 (capsid assembly;201)
D
5747 .. 6079  =  333 bp
110 amino acids  =  11.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: D (head-DNA stabilization;110)
D
5747 .. 6079  =  333 bp
110 amino acids  =  11.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: D (head-DNA stabilization;110)
E
6135 .. 7160  =  1026 bp
341 amino acids  =  38.2 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: E (capsid component;341)
E
6135 .. 7160  =  1026 bp
341 amino acids  =  38.2 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: E (capsid component;341)
Fi
7202 .. 7600  =  399 bp
132 amino acids  =  14.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Fi (DNA packaging;117)
Fi
7202 .. 7600  =  399 bp
132 amino acids  =  14.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Fi (DNA packaging;117)
Fii
7612 .. 7965  =  354 bp
117 amino acids  =  12.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Fii (head-tail joining;117)
Fii
7612 .. 7965  =  354 bp
117 amino acids  =  12.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Fii (head-tail joining;117)
Z
7977 .. 8555  =  579 bp
192 amino acids  =  21.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Z (tail component;192)
Z
7977 .. 8555  =  579 bp
192 amino acids  =  21.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Z (tail component;192)
V
8955 .. 9695  =  741 bp
246 amino acids  =  25.8 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: V (tail component;256)
V
8955 .. 9695  =  741 bp
246 amino acids  =  25.8 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: V (tail component;256)
G
9711 .. 10,133  =  423 bp
140 amino acids  =  15.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: G (tail component;140)
G
9711 .. 10,133  =  423 bp
140 amino acids  =  15.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: G (tail component;140)
H
10,542 .. 13,103  =  2562 bp
853 amino acids  =  92.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: H (tail component;853)
H
10,542 .. 13,103  =  2562 bp
853 amino acids  =  92.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: H (tail component;853)
L
13,429 .. 14,127  =  699 bp
232 amino acids  =  25.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: L (tail component;232)
L
13,429 .. 14,127  =  699 bp
232 amino acids  =  25.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: L (tail component;232)
I
14,773 .. 15,444  =  672 bp
223 amino acids  =  23.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: I (tail component;223)
I
14,773 .. 15,444  =  672 bp
223 amino acids  =  23.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: I (tail component;223)
J
15,505 .. 18,903  =  3399 bp
1132 amino acids  =  124.4 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: J (tail:host specificity;1132)
J
15,505 .. 18,903  =  3399 bp
1132 amino acids  =  124.4 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: J (tail:host specificity;1132)
lom
18,965 .. 19,585  =  621 bp
206 amino acids  =  21.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: lom (outer host membrane;206a)
lom
18,965 .. 19,585  =  621 bp
206 amino acids  =  21.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: lom (outer host membrane;206a)
orf-401
19,650 .. 20,855  =  1206 bp
401 amino acids  =  39.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf-401
orf-401
19,650 .. 20,855  =  1206 bp
401 amino acids  =  39.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf-401
orf-314
21,029 .. 21,973  =  945 bp
314 amino acids  =  32.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf-314
orf-314
21,029 .. 21,973  =  945 bp
314 amino acids  =  32.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf-314
orf206b
22,686 .. 23,918  =  1233 bp
410 amino acids  =  48.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf206b
orf206b
22,686 .. 23,918  =  1233 bp
410 amino acids  =  48.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf206b
recombination site
24,389 .. 24,390  =  2 bp
recombination site
24,389 .. 24,390  =  2 bp
orf206b
25,396 .. 26,973  =  1578 bp
525 amino acids  =  59.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf206b
orf206b
25,396 .. 26,973  =  1578 bp
525 amino acids  =  59.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf206b
int 1 binding site
27,583 .. 27,602  =  20 bp
int 1 binding site
27,583 .. 27,602  =  20 bp
int 2 binding site
27,615 .. 27,634  =  20 bp
int 2 binding site
27,615 .. 27,634  =  20 bp
int 3 binding site
27,714 .. 27,747  =  34 bp
int 3 binding site
27,714 .. 27,747  =  34 bp
int
27,812 .. 28,882  =  1071 bp
356 amino acids  =  40.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: integration protein
int
27,812 .. 28,882  =  1071 bp
356 amino acids  =  40.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: integration protein
xis
29,374 .. 29,655  =  282 bp
93 amino acids  =  10.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
xis
29,374 .. 29,655  =  282 bp
93 amino acids  =  10.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
xis
29,847 .. 30,395  =  549 bp
182 amino acids  =  20.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
xis
29,847 .. 30,395  =  549 bp
182 amino acids  =  20.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
xis
31,005 .. 31,196  =  192 bp
63 amino acids  =  7.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
xis
31,005 .. 31,196  =  192 bp
63 amino acids  =  7.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
recombination site
31,266 .. 31,267  =  2 bp
recombination site
31,266 .. 31,267  =  2 bp
bet
32,025 .. 32,810  =  786 bp
261 amino acids  =  29.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: bet (recombination;261)
bet
32,025 .. 32,810  =  786 bp
261 amino acids  =  29.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: bet (recombination;261)
gam
32,816 .. 33,232  =  417 bp
138 amino acids  =  16.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: gam (recombination;261)
submitted as bet but similarity results suggests gam
gam
32,816 .. 33,232  =  417 bp
138 amino acids  =  16.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: gam (recombination;261)
submitted as bet but similarity results suggests gam
kil
33,299 .. 33,463  =  165 bp
54 amino acids  =  6.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: kil(host-killing;54)
kil
33,299 .. 33,463  =  165 bp
54 amino acids  =  6.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: kil(host-killing;54)
ea10
33,536 .. 33,904  =  369 bp
122 amino acids  =  13.8 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: ea10 (ssb;122)
ea10
33,536 .. 33,904  =  369 bp
122 amino acids  =  13.8 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: ea10 (ssb;122)
ral
34,087 .. 34,287  =  201 bp
66 amino acids  =  7.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: ral(restriction alleviation;66)
ral
34,087 .. 34,287  =  201 bp
66 amino acids  =  7.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: ral(restriction alleviation;66)
N
35,037 .. 35,438  =  402 bp
133 amino acids  =  15.4 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: N (early gene regulator;133)
N
35,037 .. 35,438  =  402 bp
133 amino acids  =  15.4 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: N (early gene regulator;133)
Nutl binding site
35,518 .. 35,534  =  17 bp
N-utilization leftward.; putative
Nutl binding site
35,518 .. 35,534  =  17 bp
N-utilization leftward.; putative
operator-l1
35,591 .. 35,607  =  17 bp
operator-l1 (first base on comp strand)
operator-l1
35,591 .. 35,607  =  17 bp
operator-l1 (first base on comp strand)
operator-l2
35,615 .. 35,631  =  17 bp
operator-l2 (first base on comp strand)
operator-l2
35,615 .. 35,631  =  17 bp
operator-l2 (first base on comp strand)
operator-l3
35,635 .. 35,651  =  17 bp
operator-l3 (first base on comp strand)
operator-l3
35,635 .. 35,651  =  17 bp
operator-l3 (first base on comp strand)
rexb
35,825 .. 36,259  =  435 bp
144 amino acids  =  16.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: rexb (exclusion;144)
rexb
35,825 .. 36,259  =  435 bp
144 amino acids  =  16.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: rexb (exclusion;144)
rexb
36,275 .. 37,114  =  840 bp
279 amino acids  =  31.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: rexb (exclusion;144)
rexb
36,275 .. 37,114  =  840 bp
279 amino acids  =  31.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: rexb (exclusion;144)
rexb
37,227 .. 37,940  =  714 bp
237 amino acids  =  26.2 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: rexb (exclusion;144)
rexb
37,227 .. 37,940  =  714 bp
237 amino acids  =  26.2 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: rexb (exclusion;144)
operator-r3
37,951 .. 37,967  =  17 bp
operator-r3
operator-r3
37,951 .. 37,967  =  17 bp
operator-r3
operator-r2
37,974 .. 37,990  =  17 bp
operator-r2
operator-r2
37,974 .. 37,990  =  17 bp
operator-r2
operator-r1
37,998 .. 38,014  =  17 bp
operator-r1
operator-r1
37,998 .. 38,014  =  17 bp
operator-r1
cro
38,041 .. 38,241  =  201 bp
66 amino acids  =  7.4 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: cro (antirepressor; also tof;66)
cro
38,041 .. 38,241  =  201 bp
66 amino acids  =  7.4 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: cro (antirepressor; also tof;66)
rho utilization site A
38,249 .. 38,266  =  18 bp
rho utilization site A (rutA)
rho utilization site A
38,249 .. 38,266  =  18 bp
rho utilization site A (rutA)
rho utilization site B
38,282 .. 38,301  =  20 bp
rho utilization site B (rutB)
rho utilization site B
38,282 .. 38,301  =  20 bp
rho utilization site B (rutB)
cII
38,360 .. 38,653  =  294 bp
97 amino acids  =  11.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: cII (antitermination;119)
cII
38,360 .. 38,653  =  294 bp
97 amino acids  =  11.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: cII (antitermination;119)
cII
38,686 .. 39,585  =  900 bp
299 amino acids  =  33.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: cII (antitermination;119)
cII
38,686 .. 39,585  =  900 bp
299 amino acids  =  33.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: cII (antitermination;119)
cII
40,280 .. 40,570  =  291 bp
96 amino acids  =  10.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: cII (antitermination;119)
cII
40,280 .. 40,570  =  291 bp
96 amino acids  =  10.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: cII (antitermination;119)
Nin 290
41,081 .. 41,953  =  873 bp
290 amino acids  =  33.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 290 (pept unknown;290)
Nin 290
41,081 .. 41,953  =  873 bp
290 amino acids  =  33.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 290 (pept unknown;290)
Nin 60
42,090 .. 42,272  =  183 bp
60 amino acids  =  7.4 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 60 (pept unknown;60)
Nin 60
42,090 .. 42,272  =  183 bp
60 amino acids  =  7.4 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 60 (pept unknown;60)
Nin 204
42,429 .. 43,043  =  615 bp
204 amino acids  =  24.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 204 (pept unknown;204)
Nin 204
42,429 .. 43,043  =  615 bp
204 amino acids  =  24.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 204 (pept unknown;204)
Nin 221
43,224 .. 43,889  =  666 bp
221 amino acids  =  25.2 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 221 (pept unknown;221)
Nin 221
43,224 .. 43,889  =  666 bp
221 amino acids  =  25.2 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 221 (pept unknown;221)
orf-64
44,621 .. 44,815  =  195 bp
64 amino acids  =  7.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf-64
orf-64
44,621 .. 44,815  =  195 bp
64 amino acids  =  7.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf-64
R
45,493 .. 45,969  =  477 bp
158 amino acids  =  17.8 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: R (cell lysis;158)
R
45,493 .. 45,969  =  477 bp
158 amino acids  =  17.8 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: R (cell lysis;158)
nu1
191 .. 736  =  546 bp
181 amino acids  =  20.4 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: nu1; (DNA packaging;181)
nu1
191 .. 736  =  546 bp
181 amino acids  =  20.4 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: nu1; (DNA packaging;181)
W
2633 .. 2839  =  207 bp
68 amino acids  =  7.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: W (head-tail joining;68)
W
2633 .. 2839  =  207 bp
68 amino acids  =  7.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: W (head-tail joining;68)
mature peptide
2902 .. 4434  =  1533 bp
Product: processed B
mature peptide
2902 .. 4434  =  1533 bp
Product: processed B
U
8552 .. 8947  =  396 bp
131 amino acids  =  14.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: U (tail component;131)
U
8552 .. 8947  =  396 bp
131 amino acids  =  14.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: U (tail component;131)
T
10,115 .. 10,549  =  435 bp
144 amino acids  =  16.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: T (tail component;144)
T
10,115 .. 10,549  =  435 bp
144 amino acids  =  16.1 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: T (tail component;144)
M
13,100 .. 13,429  =  330 bp
109 amino acids  =  12.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: M (tail component;109)
M
13,100 .. 13,429  =  330 bp
109 amino acids  =  12.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: M (tail component;109)
K
14,276 .. 14,875  =  600 bp
199 amino acids  =  23.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: K (tail component;199)
K
14,276 .. 14,875  =  600 bp
199 amino acids  =  23.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: K (tail component;199)
orf206b
20,147 .. 20,767  =  621 bp
206 amino acids  =  20.2 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf206b
orf206b
20,147 .. 20,767  =  621 bp
206 amino acids  =  20.2 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf206b
orf-194
21,973 .. 22,557  =  585 bp
194 amino acids  =  21.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf-194
orf-194
21,973 .. 22,557  =  585 bp
194 amino acids  =  21.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf-194
orf206b
24,509 .. 25,399  =  891 bp
296 amino acids  =  34.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf206b
orf206b
24,509 .. 25,399  =  891 bp
296 amino acids  =  34.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: orf206b
recombination site
27,724 .. 27,738  =  15 bp
recombination site
27,724 .. 27,738  =  15 bp
int 4 binding site
27,814 .. 27,854  =  41 bp
int 4 binding site
27,814 .. 27,854  =  41 bp
xis
28,860 .. 29,078  =  219 bp
72 amino acids  =  8.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
xis
28,860 .. 29,078  =  219 bp
72 amino acids  =  8.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
xis
30,839 .. 31,024  =  186 bp
61 amino acids  =  6.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
xis
30,839 .. 31,024  =  186 bp
61 amino acids  =  6.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
exo
31,348 .. 32,028  =  681 bp
226 amino acids  =  25.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: exonuclease; bet (recombination;261)
exo
31,348 .. 32,028  =  681 bp
226 amino acids  =  25.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: exonuclease; bet (recombination;261)
kil
33,187 .. 33,330  =  144 bp
47 amino acids  =  5.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: kil(host-killing;54)
kil
33,187 .. 33,330  =  144 bp
47 amino acids  =  5.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: kil(host-killing;54)
ral
34,271 .. 34,357  =  87 bp
28 amino acids  =  3.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: ral(restriction alleviation;66)
ral
34,271 .. 34,357  =  87 bp
28 amino acids  =  3.7 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: ral(restriction alleviation;66)
Nutr binding site
38,265 .. 38,281  =  17 bp
N-utilization rightward; putative
Nutr binding site
38,265 .. 38,281  =  17 bp
N-utilization rightward; putative
ice
38,543 .. 38,557  =  15 bp
ice(inceptor signal for DNA replication)
ice
38,543 .. 38,557  =  15 bp
ice(inceptor signal for DNA replication)
ori iteron 1
39,034 .. 39,051  =  18 bp
ori iteron 1
39,034 .. 39,051  =  18 bp
ori iteron 2
39,054 .. 39,071  =  18 bp
ori iteron 2
39,054 .. 39,071  =  18 bp
ori iteron 3
39,078 .. 39,095  =  18 bp
ori iteron 3
39,078 .. 39,095  =  18 bp
ori iteron 4
39,101 .. 39,118  =  18 bp
ori iteron 4
39,101 .. 39,118  =  18 bp
recombination site
39,157 .. 39,158  =  2 bp
recombination site
39,157 .. 39,158  =  2 bp
recombination site
39,165 .. 39,166  =  2 bp
recombination site
39,165 .. 39,166  =  2 bp
cII
39,582 .. 40,283  =  702 bp
233 amino acids  =  26.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: cII (antitermination;119)
cII
39,582 .. 40,283  =  702 bp
233 amino acids  =  26.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: cII (antitermination;119)
Nin 146
40,644 .. 41,084  =  441 bp
146 amino acids  =  16.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 146 (pept unknown;146)
Nin 146
40,644 .. 41,084  =  441 bp
146 amino acids  =  16.6 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 146 (pept unknown;146)
Nin 57
41,950 .. 42,123  =  174 bp
57 amino acids  =  7.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 57 (pept unknown;57)
Nin 57
41,950 .. 42,123  =  174 bp
57 amino acids  =  7.0 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 57 (pept unknown;57)
Nin 56
42,269 .. 42,439  =  171 bp
56 amino acids  =  6.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 56 (pept unknown;56)
Nin 56
42,269 .. 42,439  =  171 bp
56 amino acids  =  6.3 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 56 (pept unknown;56)
Nin 68
43,040 .. 43,246  =  207 bp
68 amino acids  =  7.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 68 (pept unknown;68)
Nin 68
43,040 .. 43,246  =  207 bp
68 amino acids  =  7.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Nin 68 (pept unknown;68)
recombination site
43,884 .. 43,885  =  2 bp
recombination site
43,884 .. 43,885  =  2 bp
Q
43,886 .. 44,509  =  624 bp
207 amino acids  =  22.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Q (late gene regulator;207)
Q
43,886 .. 44,509  =  624 bp
207 amino acids  =  22.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Q (late gene regulator;207)
S
45,186 .. 45,509  =  324 bp
107 amino acids  =  11.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: S (cell lysis;107)
S
45,186 .. 45,509  =  324 bp
107 amino acids  =  11.5 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: S (cell lysis;107)
Rz
45,966 .. 46,427  =  462 bp
153 amino acids  =  17.2 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Rz (cell lysis;153)
Rz
45,966 .. 46,427  =  462 bp
153 amino acids  =  17.2 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: Rz (cell lysis;153)
leader peptide
2836 .. 2901  =  66 bp
leader peptide
leader peptide
2836 .. 2901  =  66 bp
leader peptide
C
4418 .. 5737  =  1320 bp
439 amino acids  =  45.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: C (capsid component;439)
C
4418 .. 5737  =  1320 bp
439 amino acids  =  45.9 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: C (capsid component;439)
xis
31,169 .. 31,351  =  183 bp
60 amino acids  =  6.8 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
xis
31,169 .. 31,351  =  183 bp
60 amino acids  =  6.8 kDa
Genetic Code:  Bacterial, Archaeal and Plant Plastid
Product: xis (excision;72)
ORF:  1420 .. 1677  =  258 bp
ORF:  85 amino acids  =  9.2 kDa
ORF:  2422 .. 2679  =  258 bp
ORF:  85 amino acids  =  9.8 kDa
ORF:  2836 .. 4437  =  1602 bp
ORF:  533 amino acids  =  59.5 kDa
ORF:  7678 .. 7965  =  288 bp
ORF:  95 amino acids  =  10.3 kDa
ORF:  9118 .. 9348  =  231 bp
ORF:  76 amino acids  =  8.3 kDa
ORF:  13,429 .. 14,127  =  699 bp
ORF:  232 amino acids  =  25.7 kDa
ORF:  14,773 .. 15,444  =  672 bp
ORF:  223 amino acids  =  23.1 kDa
ORF:  15,505 .. 18,903  =  3399 bp
ORF:  1132 amino acids  =  124.4 kDa
ORF:  20,089 .. 20,691  =  603 bp
ORF:  200 amino acids  =  25.0 kDa
ORF:  21,973 .. 22,557  =  585 bp
ORF:  194 amino acids  =  21.6 kDa
ORF:  29,218 .. 29,610  =  393 bp
ORF:  130 amino acids  =  14.9 kDa
ORF:  32,677 .. 32,928  =  252 bp
ORF:  83 amino acids  =  9.0 kDa
ORF:  38,686 .. 39,585  =  900 bp
ORF:  299 amino acids  =  33.9 kDa
ORF:  45,493 .. 45,969  =  477 bp
ORF:  158 amino acids  =  17.8 kDa
ORF:  191 .. 736  =  546 bp
ORF:  181 amino acids  =  20.4 kDa
ORF:  2897 .. 3244  =  348 bp
ORF:  115 amino acids  =  12.2 kDa
ORF:  4457 .. 5737  =  1281 bp
ORF:  426 amino acids  =  44.5 kDa
ORF:  5741 .. 6079  =  339 bp
ORF:  112 amino acids  =  11.9 kDa
ORF:  7163 .. 7600  =  438 bp
ORF:  145 amino acids  =  15.8 kDa
ORF:  8552 .. 8947  =  396 bp
ORF:  131 amino acids  =  14.6 kDa
ORF:  10,160 .. 10,549  =  390 bp
ORF:  129 amino acids  =  14.4 kDa
ORF:  13,100 .. 13,429  =  330 bp
ORF:  109 amino acids  =  12.5 kDa
ORF:  14,276 .. 14,875  =  600 bp
ORF:  199 amino acids  =  23.0 kDa
ORF:  18,965 .. 19,585  =  621 bp
ORF:  206 amino acids  =  21.9 kDa
ORF:  21,029 .. 21,973  =  945 bp
ORF:  314 amino acids  =  32.0 kDa
ORF:  22,037 .. 22,318  =  282 bp
ORF:  93 amino acids  =  10.8 kDa
ORF:  31,184 .. 31,474  =  291 bp
ORF:  96 amino acids  =  10.6 kDa
ORF:  31,934 .. 32,197  =  264 bp
ORF:  87 amino acids  =  9.4 kDa
ORF:  34,031 .. 34,264  =  234 bp
ORF:  77 amino acids  =  8.4 kDa
ORF:  38,300 .. 38,653  =  354 bp
ORF:  117 amino acids  =  13.5 kDa
ORF:  40,280 .. 40,570  =  291 bp
ORF:  96 amino acids  =  10.6 kDa
ORF:  41,063 .. 41,953  =  891 bp
ORF:  296 amino acids  =  34.2 kDa
ORF:  43,886 .. 44,509  =  624 bp
ORF:  207 amino acids  =  22.5 kDa
ORF:  891 .. 2636  =  1746 bp
ORF:  581 amino acids  =  66.2 kDa
ORF:  5076 .. 5345  =  270 bp
ORF:  89 amino acids  =  10.3 kDa
ORF:  6135 .. 7160  =  1026 bp
ORF:  341 amino acids  =  38.2 kDa
ORF:  7977 .. 8555  =  579 bp
ORF:  192 amino acids  =  21.6 kDa
ORF:  8586 .. 8816  =  231 bp
ORF:  76 amino acids  =  9.1 kDa
ORF:  8925 .. 9695  =  771 bp
ORF:  256 amino acids  =  26.9 kDa
ORF:  9711 .. 10,133  =  423 bp
ORF:  140 amino acids  =  15.6 kDa
ORF:  10,542 .. 13,103  =  2562 bp
ORF:  853 amino acids  =  92.3 kDa
ORF:  14,133 .. 14,363  =  231 bp
ORF:  76 amino acids  =  8.4 kDa
ORF:  14,511 .. 14,747  =  237 bp
ORF:  78 amino acids  =  9.1 kDa
ORF:  19,650 .. 20,855  =  1206 bp
ORF:  401 amino acids  =  39.9 kDa
ORF:  32,373 .. 32,672  =  300 bp
ORF:  99 amino acids  =  11.1 kDa
ORF:  34,485 .. 35,036  =  552 bp
ORF:  183 amino acids  =  21.4 kDa
ORF:  39,582 .. 40,283  =  702 bp
ORF:  233 amino acids  =  26.5 kDa
ORF:  40,644 .. 41,084  =  441 bp
ORF:  146 amino acids  =  16.6 kDa
ORF:  41,691 .. 41,975  =  285 bp
ORF:  94 amino acids  =  10.9 kDa
ORF:  42,429 .. 43,043  =  615 bp
ORF:  204 amino acids  =  24.1 kDa
ORF:  43,152 .. 43,889  =  738 bp
ORF:  245 amino acids  =  27.8 kDa
ORF:  45,186 .. 45,509  =  324 bp
ORF:  107 amino acids  =  11.5 kDa
ORF:  45,966 .. 46,427  =  462 bp
ORF:  153 amino acids  =  17.2 kDa
ORF:  71 .. 631  =  561 bp
ORF:  186 amino acids  =  21.1 kDa
ORF:  2603 .. 2884  =  282 bp
ORF:  93 amino acids  =  10.6 kDa
ORF:  4604 .. 5095  =  492 bp
ORF:  163 amino acids  =  17.5 kDa
ORF:  5372 .. 5806  =  435 bp
ORF:  144 amino acids  =  16.3 kDa
ORF:  7097 .. 7390  =  294 bp
ORF:  97 amino acids  =  10.9 kDa
ORF:  9275 .. 9631  =  357 bp
ORF:  118 amino acids  =  12.4 kDa
ORF:  9692 .. 9940  =  249 bp
ORF:  82 amino acids  =  9.0 kDa
ORF:  10,625 .. 10,870  =  246 bp
ORF:  81 amino acids  =  8.3 kDa
ORF:  11,312 .. 11,554  =  243 bp
ORF:  80 amino acids  =  8.4 kDa
ORF:  12,194 .. 12,712  =  519 bp
ORF:  172 amino acids  =  18.4 kDa
ORF:  14,108 .. 14,551  =  444 bp
ORF:  147 amino acids  =  16.2 kDa
ORF:  21,320 .. 21,577  =  258 bp
ORF:  85 amino acids  =  9.7 kDa
ORF:  22,262 .. 22,510  =  249 bp
ORF:  82 amino acids  =  9.0 kDa
ORF:  24,509 .. 25,399  =  891 bp
ORF:  296 amino acids  =  34.6 kDa
ORF:  27,335 .. 27,604  =  270 bp
ORF:  89 amino acids  =  9.7 kDa
ORF:  27,812 .. 28,882  =  1071 bp
ORF:  356 amino acids  =  40.3 kDa
ORF:  32,342 .. 32,599  =  258 bp
ORF:  85 amino acids  =  9.3 kDa
ORF:  32,816 .. 33,232  =  417 bp
ORF:  138 amino acids  =  16.3 kDa
ORF:  33,536 .. 33,904  =  369 bp
ORF:  122 amino acids  =  13.8 kDa
ORF:  35,825 .. 36,259  =  435 bp
ORF:  144 amino acids  =  16.0 kDa
ORF:  36,275 .. 37,114  =  840 bp
ORF:  279 amino acids  =  31.3 kDa
ORF:  40,064 .. 40,321  =  258 bp
ORF:  85 amino acids  =  9.1 kDa
ORF:  41,897 .. 42,121  =  225 bp
ORF:  74 amino acids  =  8.2 kDa
ORF:  44,012 .. 44,251  =  240 bp
ORF:  79 amino acids  =  8.9 kDa
ORF:  47,042 .. 47,494  =  453 bp
ORF:  150 amino acids  =  18.1 kDa
ORF:  310 .. 666  =  357 bp
ORF:  118 amino acids  =  12.8 kDa
ORF:  2536 .. 2799  =  264 bp
ORF:  87 amino acids  =  9.4 kDa
ORF:  2830 .. 3105  =  276 bp
ORF:  91 amino acids  =  9.7 kDa
ORF:  10,249 .. 10,482  =  234 bp
ORF:  77 amino acids  =  7.8 kDa
ORF:  11,155 .. 11,454  =  300 bp
ORF:  99 amino acids  =  10.6 kDa
ORF:  16,105 .. 16,350  =  246 bp
ORF:  81 amino acids  =  9.2 kDa
ORF:  16,435 .. 18,129  =  1695 bp
ORF:  564 amino acids  =  64.1 kDa
ORF:  18,553 .. 18,816  =  264 bp
ORF:  87 amino acids  =  10.3 kDa
ORF:  19,873 .. 20,619  =  747 bp
ORF:  248 amino acids  =  30.0 kDa
ORF:  20,800 .. 21,030  =  231 bp
ORF:  76 amino acids  =  7.4 kDa
ORF:  21,952 .. 22,185  =  234 bp
ORF:  77 amino acids  =  9.0 kDa
ORF:  25,396 .. 26,973  =  1578 bp
ORF:  525 amino acids  =  59.5 kDa
ORF:  29,374 .. 29,655  =  282 bp
ORF:  93 amino acids  =  10.7 kDa
ORF:  31,348 .. 32,028  =  681 bp
ORF:  226 amino acids  =  25.9 kDa
ORF:  33,187 .. 33,456  =  270 bp
ORF:  89 amino acids  =  10.1 kDa
ORF:  37,900 .. 38,145  =  246 bp
ORF:  81 amino acids  =  9.0 kDa
ORF:  41,476 .. 41,727  =  252 bp
ORF:  83 amino acids  =  9.1 kDa
ORF:  46,459 .. 46,752  =  294 bp
ORF:  97 amino acids  =  10.4 kDa
ORF:  47,572 .. 47,811  =  240 bp
ORF:  79 amino acids  =  8.6 kDa
ORF:  771 .. 1538  =  768 bp
ORF:  255 amino acids  =  29.1 kDa
ORF:  1866 .. 2153  =  288 bp
ORF:  95 amino acids  =  10.4 kDa
ORF:  7449 .. 7697  =  249 bp
ORF:  82 amino acids  =  9.2 kDa
ORF:  8286 .. 8528  =  243 bp
ORF:  80 amino acids  =  9.4 kDa
ORF:  9831 .. 10,202  =  372 bp
ORF:  123 amino acids  =  13.9 kDa
ORF:  11,718 .. 12,134  =  417 bp
ORF:  138 amino acids  =  16.6 kDa
ORF:  12,696 .. 12,959  =  264 bp
ORF:  87 amino acids  =  9.4 kDa
ORF:  14,457 .. 14,822  =  366 bp
ORF:  121 amino acids  =  12.9 kDa
ORF:  15,489 .. 15,830  =  342 bp
ORF:  113 amino acids  =  11.7 kDa
ORF:  18,129 .. 18,494  =  366 bp
ORF:  121 amino acids  =  12.9 kDa
ORF:  21,033 .. 21,353  =  321 bp
ORF:  106 amino acids  =  12.1 kDa
ORF:  22,686 .. 23,945  =  1260 bp
ORF:  419 amino acids  =  49.2 kDa
ORF:  29,847 .. 30,347  =  501 bp
ORF:  166 amino acids  =  19.2 kDa
ORF:  32,025 .. 32,810  =  786 bp
ORF:  261 amino acids  =  29.7 kDa
ORF:  35,037 .. 35,438  =  402 bp
ORF:  133 amino acids  =  15.4 kDa
ORF:  37,227 .. 37,940  =  714 bp
ORF:  237 amino acids  =  26.2 kDa
Click here to try SnapGene

Download lambda.dna file

SnapGene

SnapGene is the easiest way to plan, visualize and document your everyday molecular biology procedures

  • Fast accurate construct design for all major molecular cloning techniques
  • Validate sequenced constructs using powerful alignment tools
  • Customize plasmid maps with flexible annotation and visualization controls
  • Automatically generate a rich graphical history of every edit and procedure
Download SnapGene

SnapGene Viewer

SnapGene Viewer is free software that allows molecular biologists to create, browse, and share richly annotated sequence files.

  • Gain unparalleled visibility of your plasmids, DNA and protein sequences
  • Annotate features on your plasmids using the curated feature database
  • Store, search, and share your sequences, files and maps
Download SnapGene Viewer

Individual Sequences & Maps

BlueScribe
pEASY-T1 (linearized)
pJET1.2
pSMART LCAmp
CAG promoter
pEASY-T1 Simple (linearized)
pJET1.2 blunt
pSMART LCAmp (linearized)
chicken beta-actin promoter
pEASY-T3 (linearized)
pJW168
pSMART LCKan
CLIP-tag
pEASY-T5 Zero (linearized)
pKF 18k-2
pSMART LCKan (linearized)
CMV promoter
pEX-1
pKF 19k-2
pSP64 Poly(A)
GAL1 promoter
pEX-A
pKOV
pSP72
GST
pEX-C-GST
pLATE11 (linearized)
pSP73
HaloTag
pEX-C-His
pLATE31 (linearized)
pSpark Done (linearized)
HSV TK promoter
pEX-K
pLATE51 (linearized)
pSpark I (linearized)
lac operator
pEX-N-GST
pLATE52 (linearized)
pSpark II (linearized)
lac promoter
pEX-N-His
pLEXX-AK
pSpark III (linearized)
lac UV5 promoter
pEX-N-His-GST
pLPS-B (linearized)
pSpark IV (linearized)
lacZ
pEX1
pMAL-c5E
pSpark V (linearized)
lambda
pEX2
pMAL-c5G
pSpot1
LITMUS28
pEX3
pMAL-c5X
pSpot2
LITMUS28i
pEZSeq-Amp
pMAL-c5X-His
pSpot3
LITMUS29
pEZSeq-Amp (linearized)
pMAL-c6T
pSpot4
LITMUS38
pEZSeq-Kan
pMAL-p5E
pSTBlue-1
LITMUS38i
pEZSeq-Kan (linearized)
pMAL-p5G
pSTV28
LITMUS39
pEZ BAC
pMAL-p5X
pSTV29
M13mp18
pEZ BAC (BamHI linearized)
pMCS5
pT7Blue
M13mp19
pEZ BAC (HpaI linearized)
pMiniT
pT7Blue-2
MBP
pF1A T7
pMiniT (linearized)
pT7Blue-3
pACYC177
pF1K T7
pMiniT 2.0
pT7CFE1-CFtag
pACYC184
pF25A ICE T7
pMiniT 2.0 (linearized)
pT7CFE1-CGFP-HA-His
pAN7-1
pF25K ICE T7
pMMB190
pT7CFE1-CGST-HA-His
pANT7_cGST
pF3A WG (BYDV)
pMMB206
pT7CFE1-CHA
pANT7_nHA
pF3K WG (BYDV)
pMMB207
pT7CFE1-CHis
pAUR316
pFC20A HaloTag T7 SP6
pMMB208
pT7CFE1-CMyc
pBC KS(+)
pFC20K HaloTag T7 SP6
pMMB66EH
pT7CFE1-NFtag
pBC KS(-)
pFC30A His6HaloTag T7
pMMB66HE
pT7CFE1-NHA
pBC SK(+)
pFC30K His6HaloTag T7
pMMB67EH
pT7CFE1-NHA-CHis
pBC SK(-)
pFC7A (HQ)
pMMB67HE
pT7CFE1-NHis
pBeloBAC11
pFC7K (HQ)
pNEB193
pT7CFE1-NHis-GST
pBluescript II KS(+)
pFN18A HaloTag T7
pNEB206A (linearized)
pT7CFE1-NHis-GST-CHA
pBluescript II KS(-)
pFN18K HaloTag T7
pOSIP-CH
pT7CFE1-NMyc
pBluescript II SK(+)
pFN19A HaloTag T7 SP6
pOSIP-CO
pTOP Blunt V2 (linearized)
pBluescript II SK(-)
pFN19K HaloTag T7 SP6
pOSIP-CT
pTrcHis A
pBluescript KS(+)
pFN29A His6HaloTag T7
pOSIP-KC
pTrcHis B
pBluescript KS(-)
pFN29K His6HaloTag T7
pOSIP-KH
pTrcHis C
pBluescript SK(+)
pFN2A (GST)
pOSIP-KL
pTrcHis2 A
pBluescript SK(-)
pFN2K (GST)
pOSIP-KO
pTrcHis2 B
pBR322
pFN6A (HQ)
pOSIP-KP
pTrcHis2 C
pBS KS(+)
pFN6K (HQ)
pOSIP-KT
pTV 118N
pBS KS(-)
pGEM-11Zf(+)
pOSIP-TH
pTWV228
pBS SK(+)
pGEM-11Zf(-)
pOSIP-TO
pTXB1
pBS SK(-)
pGEM-3Z
pOSIP-TT
pTYB21
pBS(+)
pGEM-3Zf(+)
pPCR-Script Amp SK(+)
pType IIs
pBS(-)
pGEM-3Zf(-)
pPCR-Script Cam SK(+)
pTZ19R
pBSK(+) Simple-Amp
pGEM-4Z
pPTR I
pTZ19U
pBSK(+) Simple-Kan
pGEM-5Zf(+)
pPTR II
pTZ57R
pcDNA3
pGEM-7Zf(+)
pRACE (linearized)
pUAST
pcDNA3.1(+)
pGEM-7Zf(-)
pRANGER-BTB-1
pUC118
pcDNA3.1(-)
pGEM-9Zf(-)
pRANGER-BTB-2
pUC119
pCold I
pGEM-T
pRANGER-BTB-3
pUC18
pCold II
pGEM-T (linearized)
pRANGER-BTB-5
pUC19
pCold III
pGEM-T Easy
pRHA-109
pUC19L
pCold IV
pGEM-T Easy (linearized)
pRHA-113
pUC57
pCold TF
pGGA
pRHA-67
pUC57-Kan
pCR-XL-2-TOPO
pGGAselect
pRSET A
pUC57-Simple
pCR-XL-2-TOPO (linearized)
PGK promoter
pRSET B
pUCmu
pDD
pGS-21a
pRSET C
pVLT31
pDNR-Dual
pH6HTC His6HaloTag T7
pSB1C3
pVLT33
pDNR-LIB
pH6HTN His6HaloTag T7
pSC101
pVLT35
pE-SUMOpro Amp
pHP45(omega)
pSEAP2-Basic
pYES1L
pE-SUMOpro Kan
pHP45(omega)-Km
pSF-Core
pZErO-2
pE-SUMOpro3 Amp
pHP45(omega)-Tc
pSMART BAC v2.0
SNAP-tag
pE-SUMOpro3 Kan
pHSG298
pSMART BAC v2.0 (BamHI linearized)
SP6 promoter
pE-SUMOstar Amp
pHSG299
pSMART BAC v2.0 (EcoRI linearized)
SV40 promoter
pE-SUMOstar Kan
pHSG396
pSMART BAC v2.0 (HindIII linearized)
T3 promoter
pEASY-Blunt (linearized)
pHSG398
pSMART FOS v2.0 (linearized)
T5 promoter
pEASY-Blunt E1 (linearized)
pHY300PLK
pSMART HCAmp
T7 promoter
pEASY-Blunt E2 (linearized)
pICOz
pSMART HCAmp (linearized)
tac promoter
pEASY-Blunt Simple (linearized)
pInvRecA
pSMART HCKan
trc promoter
pEASY-Blunt Zero (linearized)
pJAZZ-OC
pSMART HCKan (linearized)
phiX174
pEASY-Blunt3 (linearized)
pJAZZ-OK

Plasmid Sets

Basic Cloning Vectors
I.M.A.G.E. Consortium Plasmids
pET & Duet Vectors (Novagen)
TA and GC Cloning Vectors
Coronavirus Resources
Insect Cell Vectors
pGEX Vectors (GE Healthcare)
TOPO Cloning Vectors
CRISPR Plasmids
Luciferase Vectors
Plant Vectors
Viral Expression & Packaging Vectors
Fluorescent Protein Genes & Plasmids
Lucigen Vectors
Qiagen Vectors
Yeast Plasmids
Gateway® Cloning Vectors
Mammalian Expression Vectors
Structural Genomics Vectors

The maps, notes, and annotations in the zip file on this page are copyrighted material. This material may be used without restriction by academic, nonprofit, and governmental entities, except that the source must be cited as ’’www.snapgene.com/resources’’. Commercial entities must contact GSL Biotech LLC for permission and terms of use.

Discover the most user-friendly molecular biology experience.
Try for Free
